Ricoh MP C307

Page Keeper Type M28 (D3DQ-17)
119
2. Remove the screw, and lift up the original tray [B].
3. Open the ADF [A], and release the five tabs of the ADF rear cover by using a thin screwdriver.
4. Remove the ADF rear cover [A].
5. Close the ADF.
