Ricoh MP C307

Page Keeper Type M28 (D3DQ-17)
123
Installing the double-feed sensor (receiver)
1. Disconnect the harness [A] of the ADF top cover [B] from ADF relay board (CN5), and release the clamp.
2. Remove the harness [A] from the harness guide.
3. Remove the ADF top cover [A].
