Ricoh MP C307

Fusing
281
5. Remove the springs [B], which are on both ends of the separation plate [A], from the holes in the frame.
( × 2)
6. Remove the springs [B], which are on both ends of the separation plate [A], from the holes in the
separation plate. ( × 2)
7. Rotate the separation plate [A], and remove it from the frame.
