Electrical Components
342
Temperature/Humidity Sensor
1. Pull out the paper tray.
2. Remove the front lower cover [A]. ( × 1)
3. Remove the temperature/humidity sensor [A]. ( × 1, × 1)
Image Creation Temperature Sensor
1. Remove the toner transport section. (Toner Transport Section)
To Next Page
