No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
3. Replace the PCDU (if the TD sensor works incorrectly)
4. Replace the harness between the BiCU and the TD sensor.
5. Replace the BiCU.
Check the SC’s branch number (-** part) and do the above steps for the corresponding color.
• If the last digit of the SC’s branch number (-**) is:
1 or 6, then do the above steps for K
2 or 7, then do the above steps for M
3 or 8, then do the above steps for C
4 or 9, then do the above steps for Y
SC682 Details
No. Description Cause
682 01 - 04 Invalid device ID Noise, Incorrect connection, Malfunction
06 - 09 Channel error Noise, Incorrect connection, Malfunction
11 - 14 Device Error Noise, Incorrect connection
16 - 19 Communication error (interrupted) Noise, Incorrect connection
21 - 24 Communication timeout Noise, Incorrect connection, Malfunction
26 - 29 Device stops (logically) Noise, Incorrect connection, Malfunction
31 - 34 Full of buffer (request) Noise, Incorrect connection, Malfunction
36 - 39 Verification error Noise, Incorrect connection
51 Verification error (during storing to EEPROM) Noise
52 Verification error (SRAM) Noise
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
SC687-00 D PER Not Received Error
• Unable to receive the PER command of the I/F commands from the controller.
• Unable to prepare the image data with the controller.
• Communication error
• Inside of the controller defective
Cycle the main power off/on.
