Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-88 DS2000E Programming Guide
:CURSor:MANual:CAY
:CURSor:MANual:CBY
Syntax
:CURSor:MANual:CAY <ay>
:CURSor:MANual:CAY?
:CURSor:MANual:CBY <by>
:CURSor:MANual:CBY?
Description
Set or query the vertical position of cursor A (Y cursor) in manual measurement with cursor.
Set or query the vertical position of cursor B (Y cursor) in manual measurement with cursor.
Parameter
Name Type Range Default
<ay> Integer 0 to 399 100
<by> Integer 0 to 399 300
Explanation
The horizontal and vertical positions of the cursor are defined by the pixel coordinate of the screen. The
pixel coordinate of the screen ranges from (0,0) to (700,400). Wherein, (0,0) is located at the left top
corner of the screen, and (700,400) is located at the right bottom corner of the screen. The horizontal
pixel range is from 0 to 699, and the vertical pixel range is from 0 to 399.
Return Format
The query returns an integer between 0 and 399.

Rigol DS2000E Series Specifications

General

Bandwidth	70 MHz to 200 MHz
Channels	2 or 4
Vertical Sensitivity	1 mV/div to 10 V/div
Vertical Resolution	8-bit
Timebase Range	2 ns/div to 50 s/div
Memory Depth	14 Mpts
Input Impedance	1 MΩ ± 1%
Trigger Modes	Edge, Pulse, Video
Waveform Capture Rate	50, 000 wfm/s
Interfaces	USB, LAN
Power Supply	100-240 VAC
Display	8-inch WVGA (800x480) LCD
