Rigol DS2000E Series Programming Guide

2 Command System RIGOL
DS2000E Programming Guide
2-37
:BUS<n>:SPI:SDA:THReshold
Syntax
:BUS<n>:SPI:SDA:THReshold <thre>
:BUS<n>:SPI:SDA:THReshold?
Description
Set or query the data channel threshold of SPI decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<thre> Real (-5 x VerticalScale - OFFSet) to (+5 x VerticalScale - OFFSet) 0
Note: For the VerticalScale, refer to the :CHANnel<n>:SCALe command. For the OFFSet, refer to
the
:CHANnel<n>:OFFSet command.
Return Format
The query returns the data channel threshold of SPI decoding on the specified bus in scientific notation.
:BUS<n>:SPI:DBITs
Syntax
:BUS<n>:SPI:DBITs <width>
:BUS<n>:SPI:DBITs?
Description
Set or query the number of bits of data of SPI decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<width> Integer 4 to 32 8
Return Format
The query returns an integer between 4 and 32.
