Rigol DS2000E Series Programming Guide

RIGOL 2 Command System
2-38 DS2000E Programming Guide
:BUS<n>:SPI:ENDian
Syntax
:BUS<n>:SPI:ENDian <endian>
:BUS<n>:SPI:ENDian?
Description
Set or query the endian of data transmission of SPI decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<endian> Discrete {MSB|LSB} MSB
Return Format
The query returns MSB or LSB.
:BUS<n>:SPI:OFFSet
Syntax
:BUS<n>:SPI:OFFSet <val>
:BUS<n>:SPI:OFFSet?
Description
Set or query the vertical offset of SPI decoding on the specified bus.
Parameter
Name Type Range Default
<n> Discrete {1|2} --
<val> Integer
Normal
[1]
: -166 to 148
Statistic
[2]
: -163 to 143
Half screen
[3]
: -103 to 52
0
Note
[1]
: The screen display is normal and the statistic function is not enabled (refer to
the
:MEASure:STATistic:DISPlay command).
Note
[2]
: The screen display is normal and the statistic function is enabled (refer to the :MEASure:STATistic:DISPlay
command).
Note
[3]
: The screen is divided into two windows (refer to the :TIMebase:DELay:ENABle and :CALCulate:FFT:SPLit
commands).
Explanation
 Before using this command, enable the bus display (refer to the
:BUS<n>:DISPlay command).
 When the data line is located in the middle of the screen, <val> is 0; when it is located above the
middle of the screen, <val> is positive; when it is located below the middle of the screen, <val> is
negative.
