8. PARAMETER DESCRIPTION
IMR02C15-E4
8-69
Dummy
F04
Event 1 set value (EV1’) [low]
Event 2 set value (EV2’) [low]
Event 3 set value (EV3’) [low]
Event 4 set value (EV4’) [low]
Link to the Event 1 to Event 4 set value [low] in the Parameter setting mode.
For details of Event 1 set value (EV1’) [low] to Event 4 set value (EV4’)
[low], refer to 8.4.2 Parameter setting item (P. 8-22).
Related parameter
Parameter setting mode:
• Event 1 set value (EV1) <Event 1 set value (EV1) [high]> to
Event 4 set value (EV4) <Event 4 set value (EV4) [high]> (P. 8-20)
• Event 1 set value (EV1’) [low] to Event 4 set value (EV4’) [low] (P. 8-22)
Engineering mode:
• Event 1 set value (EV1) <Event 1 set value (EV1) [high]> to
Event 4 set value (EV4) <Event 4 set value (EV4) [high]> (P. 8-68)
• Event 1 type to Event 4 type (P. 8-101)
• Event 1 hold action to Event 4 hold action (P. 8-110)
• Event 1 differential gap to Event 4 differential gap (P. 8-113)
• Event 1 output action at input burnout to
Event 4 output action at input burnout (P. 8-115)
• Energized/De-energized of Event 1 output to
Energized/De-energized of Event 4 output (P. 8-116)
• Event 1 timer to Event 4 timer (P. 8-118)
• Event 1 interlock to Event 4 interlock (P. 8-120)
EV1`
EV2`
EV3`
EV4`
