8. PARAMETER DESCRIPTION
IMR02C15-E4
8-70
Dummy
F04
F04 block selection (no display)
Hide parameter symbols of in the Parameter setting mode from the display.
Data range Factory set value
0: Display
1: No display
0
When “No display” is selected, the parameters of Parameter setting mode
are not displayed; however, F04 parameters are displayed.
For details of setting example, refer to 6.7 Display/No display Setting of
Mode Screens (P. 6-32, P. 6-37).
Related parameter
Parameter setting mode:
• Event 1 set value (EV1) <Event 1 set value (EV1) [high]> to
Event 4 set value (EV4) <Event 4 set value (EV4) [high]> (P. 8-20)
• Event 1 set value (EV1’) [low] to Event 4 set value (EV4’) [low] (P. 8-22)
Engineering mode:
• Event 1 set value (EV1) <Event 1 set value (EV1) [high]> to
Event 4 set value (EV4) <Event 4 set value (EV4) [high]> (P. 8-68)
• Event 1 set value (EV1’) [low] to Event 4 set value (EV4’) [low] (P. 8-69)
Description of function
Hide parameters of the Parameter setting mode from the display. Each parameter of Parameter setting
mode link to the Engineering mode from F01 to F10. The parameters of the Parameter setting mode
linked to the parameters of the Engineering mode is not displayed when “No display” is set to F04
block selection. Those parameters of the Parameter setting mode link to F04 block of the Engineering
mode.
S
.
F04
Engineering mode
Function block 04 (F04)
Parameter setting mode
Not displayed when set to
“1: No display” in
F04 block selection (no display).
Event 1 set value (EV1) < Event 1 set
value (EV1) [high]> to
Event 4 set value (EV4) < Event 4 set
value (EV4) [high]>
Event 1 set value (EV1’) [low] to
Event 4 set value (EV4’) [low]
F04 block selection (no display)
Event 1 set value (EV1) < Event 1 set
value (EV1) [high]> to
Event 4 set value (EV4) < Event 4 set
value (EV4) [high]>
Event 1 set value (EV1’) [low] to
Event 4 set value (EV4’) [low]
Parameter of the F04 block linked
to the Parameter setting mode.
