8. PARAMETER DESCRIPTION
IMR02C15-E4
8-89
Continued from the previous page.
Data range Factory set value
33: Voltage input 0 to 1 V DC
34: Voltage input 0 to 5 V DC
35: Voltage input 0 to 10 V DC
36: Voltage input 1 to 5 V DC
37: Current input 0 to 20 mA DC
38: Current input 4 to 20 mA DC
Programmable range
−1999 to +9999
The decimal point
position is selectable
0.0 to 100.0
Do not set to any number which is not described in the input range
table above. This may cause malfunctioning.
If the Input type is changed, the Decimal point position, the Input scale
high and the Input scale low are initialized. It is required to reset the
settings.
For the parameters which will be initialized if the Input type is changed,
refer to îš„ When input type (INP) is changed (P. 8-52).
Connect a 250 Ω shunt resistor to the measuring input terminals number 11
and 12 for current input (0 to 20 mA DC and 4 to 20 mA DC)
Related parameters
Engineering mode:
• Decimal point position (P. 8-90)
• Input scale high (P. 8-91)
• Input scale low (P. 8-91)
To Next Page
