RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4
8-90
Dummy
F21
Decimal point position
Use to select the Decimal point position of the input range.
Data range Factory set value
0: No decimal place
1: One decimal place
2: Two decimal places
3: Three decimal places
TC/RTD input: 0 or 1
Voltage (V)/Current (I) inputs: 0 to 3
Based on model code
Related parameters
Engineering mode:
• Input type (P. 8-88)
• Input scale high (P. 8-91)
• Input scale low (P. 8-91)
F21.
Burnout direction
Use to select Burnout direction in input break. When input break is detected by
the controller, the measured value will go either upscale or downscale according
to the Burnout direction setting.
Data range Factory set value
0: Upscale
1: Downscale
0
The Burnout direction setting is effective only for thermocouple input.
For the following types of input, the action when an input break occurs is
fixed, regardless of the Burnout direction setting.
RTD input: Upscale
Voltage input: Downscale or Display of about 0 V
Current input: Downscale or Display of about 0 mA
