RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4
8-91
Dummy
F21
Input scale high
Input scale low
Use to set the high limit and low limit of the input scale range.
Data range Factory set value
Input scale high
TC/RTD inputs:
Input scale low to Maximum value of the
selected input range
Maximum value of the
selected input range
Voltage (V)/Current (I) inputs:
−1999 to +9999 (Varies with the setting of the
Decimal point position) *
100.0
Input scale low
TC/RTD inputs:
Minimum value of the selected input range to
Input scale high
Minimum value of the
selected input range
Voltage (V)/Current (I) inputs:
−1999 to +9999 (Varies with the setting of the
Decimal point position) *
0.0
* Input scale high < Input scale low
Related parameters
Engineering mode:
• Input type (P. 8-88)
• Decimal point position (P. 8-90)
• Setting limiter high, Setting limiter low (P. 8-93)
PGSH
PGSL
