RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4
8-92
 Description of function
The input range can be changed for temperature input (TC/RTD).
Example [temperature input]:
When the range of −200 to +1372 °C for thermocouple type K is changed to 0 to 400 °C
Input scale low 0 °C
Input scale high 400 °C
Input span 400 °C
Input span 1572 °C
Input range
Maximum value of the
selected input range
+1372°C
Minimum value of the
selected input range
−200 °C
When the scale for temperature input is changed, it is recommended that the change
should be within the input range. If any value exceeds the recommended input range,
input resolution may vary.
For voltage (V)/current (I) inputs, display scaling can be made in the range of −1999 to +9999.
Example [Voltage (V)/Current (I) inputs]:
When the input scale is changed to “0.0 to 50.0” from “0.0 to 100.0” at a voltage input of
1 to 5 V DC
When the voltage input is 1 V DC: Displays the “0.0” to the SV display.
When the voltage input is 5 V DC: Displays the “100.0” to the SV display.
Voltage input 1 V DC
Voltage input 5 V DC
Input scale low
0.0
Input scale high
100.0
Scale
change
When the voltage input is 1 V DC: Displays the “0.0” to the SV display.
When the voltage input is 5 V DC: Displays the “50.0” to the SV display.
Voltage input 1 V DC Voltage input 5 V DC
Input scale low
0.0
Input scale high
50.0
