RKC INSTRUMENT RB Series User Manual

8. PARAMETER DESCRIPTION
IMR02C15-E4
8-116
Dummy
F41
Energized/De-energized of Event 1 output
F42
Energized/De-energized of Event 2 output
F43
Energized/De-energized of Event 3 output
F44
Energized/De-energized of Event 4 output
Use to select the Energized or De-energized for the digital output 1 (DO1).
However, the FAIL alarm is fixed to “De-energized.” (When at FAIL alarm
occurrence: Contact opened)
Use to select the Energized or De-energized for the digital output 2 (DO2).
However, the FAIL alarm is fixed to De-energized. (When at FAIL alarm
occurrence: Contact opened)
Use to select the Energized or De-energized for the digital output 3 (DO3).
However, the FAIL alarm is fixed to De-energized. (When at FAIL alarm
occurrence: Contact opened)
Use to select the Energized or De-energized for the digital output 4 (DO4).
However, the FAIL alarm is fixed to De-energized. (When at FAIL alarm
occurrence: Contact opened)
Data range Factory set value
0: Energized
1: De-energized
0
Related parameters
Parameter setting mode
• Event 1 set value (EV1) to Event 4 set value (EV4) (P. 8-20)
• Event 1 set value (EV1) [high] to Event 4 set value (EV4) [high] (P. 8-20)
• Event 1 set value (EV1’) [low] to Event 4 set value (EV4’) [low] (P. 8-22)
Engineering mode:
• Event 1 type to Event 4 type (P. 8-101)
• Event 1 hold action to Event 4 hold action (P. 8-110)
• Event 1 differential gap to Event 4 differential gap (P. 8-113)
• Event 1 output action at input burnout to Event 4 output action at input
burnout (P. 8-115)
• Event 1 timer to Event 4 timer (P. 8-118)
• Event 1 interlock to Event 4 interlock (P. 8-120)
EXC1
EXC2
EXC3
EXC4
