7 Block codes for extended host interface
Roche Diagnostics
COBAS INTEGRA 400 plus analyzer/Cedex Bio HT Analyzer · Software version 3.6/5.1 · Host Interface Manual · Version 1.24
Block codes for extended host interface 121
Block 03: Control Result
Block 02 is transmitted to the host if all of the following
conditions are met:
• After receiving a result request
• If an accepted and not yet transmitted control result is
available
• If the instrument is configured accordingly
Results collated by test ID Result type selector 01 or 09 is used.
• m = 1 (one Test ID per result block)
• n = 1 to 6
q Results of different control orders are not collated.
Results collated by control ID Result type selector 06 is used.
• m = 1 to # of available tests (m is the number of tests
with not yet transmitted QC results)
• n = 1 (one control ID per result block)
Line code Description Iteration
(1)
(1) w = 1 to 141. The value of w can be different from 1 only if the result
was measured using an absorbance test (Line 06). There are 141
possible lines since each line is produced for every cycle (max 141).
55 Test ID
1 to m
01 Result Time
02 Control ID
1 to n00 Result Data
06/08/09 Raw Data 1 to w
y Block 03
