Remote Control
R&S
®
RTM20xx
436User Manual 1317.4726.02 ─ 01
Suffix:
<m>
.
0..15
Number of the digital channel.
Channel groups: 0..3; 4..7; 8..11; 12..15
Parameters:
<ThresholdLevel> *RST: 1.4
Default unit: V
DIGital<m>:THCoupling
Applies the last defined threshold and hysteresis values to all digital channels.
Suffix:
<m>
.
0..15
Number of the digital channel
Parameters:
<ThresholdCoupling> ON | OFF
DIGital<m>:Hysteresis
Defines the size of the hysteresis to avoid the change of signal states due to noise. The
setting applied to the channel group to which the indicated digital channel belongs.
Suffix:
<m>
.
0..15
Number of the digital channel.
Channel groups: 0..3; 4..7; 8..11; 12..15
Parameters:
<Hysteresis> MAXimum | ROBust | NORMal
DIGital<m>:LABel <Label>
Defines a label for the indicated digital channel.
Suffix:
<m>
.
0..15
Number of the digital channel
Parameters:
<Label> String value
String parameter
Example:
DIGital4:LABel "Data"
Defines the label "Data" dor digital channel D4.
DIGital<m>:POSition <Position>
Sets the vertical position of the indicated vertical channel.
Command Reference
