Remote Control
R&S
®
RTM20xx
437User Manual 1317.4726.02 ─ 01
Suffix:
<m>
.
0..15
Number of the digital channel
Parameters:
<Position> Vertical position in divisions
Default unit: div
DIGital<m>:LABel:STATe
Displays or hides the label of the indicated digital channel.
Suffix:
<m>
.
0..15
Number of the digital channel
Parameters:
<State> ON | OFF
*RST: OFF
DIGital<m>:SIZE <Size>
Sets the size of the indicated vertical channel.
Suffix:
<m>
.
0..15
Number of the digital channel
Parameters:
<Size> SMALl | MEDium | LARGe
*RST: SMAL
15.2.14.2 Parallel Buses
● Parallel Bus - Configuration..................................................................................437
● Parallel Clocked Bus - Configuration....................................................................438
● Parallel Buses - Decode Results...........................................................................439
Parallel Bus - Configuration
BUS<b>:PARallel:WIDTh <BusWidth>
Sets the number of lines to be analyzed.
Suffix:
<b>
.
1..4
Selects the bus.
Note: SPI/SSPI and UART protocols occupy two bus lines.
Command Reference
