8RU
UHDTV1
4RU
UHDTV1
8RU HD4RU HDResource
2
(vid+alpha)
2
(vid+alpha)
4
4ME-Store
Channels
8 Gigabytes per MEME-Store RAM
CACHE
3,000 frames in SD or 773 frames in 3G or
1080i
Media-Store
Capture
31,837 ClipsClip Register
List (VTR/Video
Server)
Notes:
1
Only available on the MultiProcessor Input board.
2
Output Proc Amp/Color Correctors are not available
on the Evertz
®
IP Output board.
3
A DVE channel is made up of 2 channel resources
(video + alpha). These channel resources can be used
separately for 2 Preset Pattern (PST PATT) keys per
DVE channel.
Rack Requirements
The ambient temperature inside a rack-mount cabinet
may be greater than the ambient temperature within a
room. To ensure your switcher operates within its the
maximum operating temperature range, maintain the
following minimum dimensions within the equipment
rack:
• 3 inches of clearance on both the right and left-hand
sides of the switcher frame with unrestricted vertical
airow.
• 2RU of space, or the equivalent, for intake air at the
bottom of the rack.
• 4RU of space, or the equivalent, for exhaust air at the
top of the rack (open equipment rack top for
example).
Hardware Weights
WeightHardware
59lbs (26.8kg)4RU Frame
92lbs (41.7kg)8RU Frame
48lbs (21.8kg)A1S Panel
57lbs (25.9kg)A2M Panel
62lbs (28.1kg)A2X Panel
75lbs (34.0kg)A3 Panel
74lbs (33.6kg)A3M Panel
WeightHardware
103lbs (46.7kg)A4 Panel
Operating Temperature
The switcher has been qualiîš¿ed at an operational
temperature range of 0-35°C (32-95°F).
System Timing
The switcher has the following system timing
characteristics:
• All video inputs are zero-time relative to reference
input
• Auto timing correct for inputs out of sync by up to ±
¼ line (16us)
LTC Timecode Input
ValueSpecification
0.5-2.0V (1.0V nominal)Signal Level
600 ohm, soft-selectableTermination
Video Input Specifications
ValueInput Specification
>40m @ 12Gb/sEqualization (using Belden
1694A cable)
>50m @ 3Gb/s
>75m @ 1.5Gb/s
>150m @ 270Mb/s (5°-40°C)
75 ohms, terminating
Impedance
SMPTE
259M/292M/424M/ST-2082
(non-looping)
Video Inputs, SDI
Standard Definition — analog
black
Reference Inputs
(non-terminating, looping)
High Definition — tri-level sync
Video Output Specifications
ValueOutput Specification
>4dB 6GHz to 12GHzReturn Loss
>7dB 3GHz to 6GHz
>10dB 1.485GHz to 3GHz
>15dB 5MHz to 1.485GHz
110 • Specifications — Acuity Setup Manual (v9.2)
