Re-entry Depth
Allows you to have the switcher either prevent or allow
re-entry chains of more than 4 MEs. For example, ME
1 -> ME 2 -> ME 3 -> ME 4.
Press HOME > Setup > Personality and use the
Option knob to select Re-entry Depth.
Note: Re-entry chains of more than 4 MEs can cause line drops.
• Prevent — can only create re-entry chains up to 4
MEs deep.
• Warn — can create re-entry chains over 4 MEs deep,
but a pop-up is displayed.
• Allow — can create re-entry chains over 4 MEs deep.
Re-entry Loops
Allows you to have the switcher either prevent or allow
an ME re-entry feedback loop. If Re-entry Loops is set
you On, you are able to re-enter ME 1 into ME 2, and
re-enter ME 2 into ME 1.
Press HOME > Setup > Personality and use the
Option knob to select Re-entry Loops.
• Off — the switcher block re-entry loops. If a
crosspoint is selected that would cause a re-entry
loop, a popup is displayed and the crosspoint is not
selected. If the crosspoint selection is contained in a
memory, Black is selected instead.
• On — the switcher not block re-entry loops. A popup
is displayed.
Roll Clip Mode
Determines how the ROLL CLIP button behaves when
a server is selected on the preview bus. This setting is
applied to all MEs on the switcher.
Press HOME > Setup > Personality and use the
Option knob to select Roll Clip Mode.
Note: The option is locked to Arm if OverDrive
®
is controlling
the switcher.
• Play — allows you to play a server clip directly by
pressing the ROLL CLIP button on the Transition
module. Once pressed, the clip will start to play and
will have to be taken on-air manually with a
transition.
• Arm — allows you to have the server play the clip
with the next transition performed in the Transition
module that the ROLL CLIP button is on, or lit, in.
This can be used to roll multiple servers if they are
re-entered. Once pressed, the clip will only start to
play when a cut or auto transition is performed. You
can also play the clip by double-pressing the
crosspoint button on the same ME.
• Armed Always — locks the switcher in Arm mode
and does not allow the ROLL CLIP button to be
turned off.
Roll Clip On-Air Only
Determines how to play a clip based on the ME On-Air
status.
Press HOME > Setup > Personality and use the
Option knob to select Roll Clip On-Air Only.
• Always — always play a server clip even if the ME
is not On-Air.
• On-Air Only — play a server clip only when the
ME is On-Air.
Shift All Buses on a Row
Sets whether all buses on a panel row are shifted when
a SHIFT button on that row is pressed.
Press HOME > Setup > Personality and use the
Option knob to select Shift All Buses.
• Off — the shift button only affects the bus it is
pressed on.
• On — the shift button affects all the buses on the
same panel row. All the buses are shifted.
Shift Locking
Sets whether double-pressing the SHIFT button on a
crosspoint bus toggles shift on.
Press HOME > Setup > Personality and use the
Option knob to select Shift Locking.
Note: If shift lock is active on an ME, the mnemonics for that
ME switch to a two-line format.
• Off — the shift button function normally.
• On — the bus remain shifted when the shift button
is double-pressed. Pressing the shift button again
returns the bus to unshifted.
Show Attached CCs
Allows you to light all buttons that have a custom control
attached to them.
Press HOME > Setup > Personality and use the
Option knob to select Show Att'd Macros.
• Off — buttons with attached custom controls are not
lit.
• On — buttons with attached custom controls are lit
with the Attached Macros color scheme color.
48 • Personality — Acuity Setup Manual (v9.2)
