5. Use the Mode knob to select when you want to tally
the selected source.
• On Air — when the source is on-air. The source
is on-air when it is included in the program
output of an ME that is tallied.
• Preview — when the source is on preview.
• BnkXAuxY — when the source is active on the
selected aux bus.
• Any Aux Bus — when the source is active on
any aux bus.
• Preset — when the source is active on the
preset of any ME.
• ME X PGM Y — when the source is active on
the selected program output of the selected ME.
• ME X PST Y — when the source is active on
the selected preset output of the selected ME.
6. Press HOME > Confirm.
To Set Up When a Tally is Triggered
By default, the highest number ME in the switcher is
tallied as the program ME. Anything selected or
re-entered on this ME is considered on-air.
1. Press HOME > Setup > Installation > Output >
More > ME / Aux Tally.
2. Use the Bus knob to select the type of bus you want
to tally.
• ME — select an ME
• Aux — select an aux bus
• Aux Mix/Key — select an AuxKey
3. Use the ME/Aux/Aux Mix/Key knob to select the
ME, aux bus, or AuxKey that you want to set up the
tally for.
Tip: The ME X B selections represent the B-side of a split
ME.
4. Use the Tally knob to select whether sources
selected on this ME, aux bus, or AuxKey are always
tallied (Always), or are only tallied when they are
selected or re-entered on the program ME (On Air).
30 • Video Input Setup — Acuity Setup Manual (v9.2)
