Ross Acuity 4810AR-002 User Manual

Document Information
• Ross Part Number: 4820DR-120-09.2
• Release Date: January, 2020. Printed in Canada
The information contained in this document is subject to
change without notice or obligation.
Copyright
©
2020 Ross Video Limited, Ross
®
, Acuity
®
, OverDrive
®
,
and any related marks are trademarks or registered
trademarks of Ross Video Limited. All other trademarks
are the property of their respective companies. PATENTS
ISSUED and PENDING. All rights reserved. No part of
this publication may be reproduced, stored in a retrieval
system, or transmitted in any form or by any means,
mechanical, photocopying, recording or otherwise,
without the prior written permission of Ross Video.
While every precaution has been taken in the preparation
of this document, Ross Video assumes no responsibility
for errors or omissions. Neither is any liability assumed
for damages resulting from the use of the information
contained herein.
Microsoft
®
, Windows
®
, Windows XP
®
, and Internet
Explorer
®
are either registered trademarks or trademarks
of Microsoft Corporation in the United States and/or
other countries.
Macintosh
®
, and OS X
®
are trademarks of Apple Inc.,
registered in the U.S. and other countries.
Fedora
®
and the Innity design logo are trademarks of
Red Hat, Inc.
Oracle
®
and Java
™
are registered trademarks of Oracle
and/or its afliates. Other names may be trademarks of
their respective owners.
Python
™
and PyCon
™
are trademarks or registered
trademarks of the Python Software Foundation.
Firefox
®
and Mozilla
®
are trademarks or registered
trademarks of the Mozilla Foundation.
Google
®
and Google Chrome
™
and the Google logo are
registered trademarks of Google Inc.
VESA
®
and DisplayPort
™
are trademarks owned by the
Video Electronics Standards Association (VESA
®
) in
the United States and other countries.
This product includes software developed by Jordan
Ritter.
Wireshark and the "n" logo are registered trademarks
of the Wireshark Foundation.
Patents
Patent numbers US 7,034,886; US 7,508,455; US
7,602,446; US 7,802,802 B2; US 7,834,886; US
7,914,332; US 8,307,284; US 8,407,374 B2; US
8,499,019 B2; US 8,519,949 B2; US 8,743,292 B2; US
D752,530 S; GB 2,419,119 B; GB 2,447,380 B; and other
patents pending.
Important Regulatory and Safety
Notices to Service Personnel
Before using this product and any associated equipment,
refer to the “ Important Safety Instructions ” listed
in the front of your Setup Manual to avoid personnel
injury and to prevent product damage.
The switcher makes use of a number of individual
component products to make up a complete system. The
Important Safety Instructions section of this manual is
intended to compliment individual OEM product manuals
and the User must refer to, and heed, any safety
instructions outlined in these supplementary product
manuals. Separate manuals are included for the following
component products:
• Acuity Rack Panel
• Evertz
®
IP Input Board
• Evertz
®
IP Output Board
Product may require specic equipment, and/or
installation procedures to be carried out to satisfy certain
regulatory compliance requirements. Notices have been
included in this publication to call attention to these
specic requirements.
This product has been determined to be compliant with
the applicable standards, regulations, and directives for
the countries where the product is marketed.
Compliance documentation, such as certication or
Declaration of Compliance for the product is available
upon request by contacting techsupport@rossvideo.com.
Please include the product; model number identiers and
serial number and country that compliance information
is needed in request.
Symbol Meanings
Protective Earth: This symbol identifies a Protective
Earth (PE) terminal, which is provided for connection
of the supply system's protective earth (green or
green/yellow) conductor.
Important: This symbol on the equipment refers you
to important operating and maintenance (servicing)
instructions within the Product Manual Documentation.
Failure to heed this information may present a major
risk of damage or injury to persons or equipment.
Acuity Setup Manual (v9.2) — Document Information • iii

Ross Acuity 4810AR-002 Specifications

General

Brand	Ross
Model	Acuity 4810AR-002
Category	Switch
Language	English
