Figure 32: The Static recording takes snapshots of the pressure distribution under the
client's feet while standing on the plate.
The Static recording stage (Figure 32) consists of a large canvas displaying the activity
on the plate. Click Take snapshot (F5) to make a snapshot of the current pressure
distribution. The application keeps the latest snapshot and displays it at the topright.
Click Next to save the last snapshot. Click Skip to discard the static measurement.
To prevent accidental skipping the application guards Skip with a
confirmation dialog. To disable this behavior consult the Settings dialog
(Section 6.4)
.
Balance recording The balance measurement is a dynamic measurement capturing
the pressure distribution under the client's feet and the displacement of the center of
pressure (COP) while the client is standing on the plate.
Figure 33: The balance measurement captures the pressure distribution under the
client's feet while standing on the plate.
The Balance recording stage (Figure 33) shows a large preview canvas split into four
