Installing the Access Point
ZoneFlex 7025 Physical Installation
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 101
ZoneFlex 7025 Physical Installation
This section describes physical installation instructions for mounting the ZoneFlex
7025 to an electrical outlet box.
CAUTION! The AP and all interconnected equipment must be installed indoors
within the same building, including the PoE powered network connection as
described by Environment A of the 802.3af standard.
CAUTION! Ensure that you use a Cat5e or better Ethernet cable to supply PoE
power and LAN connectivity running to the outlet box where the AP will be installed.
Continue with the following:
• Mounting the ZoneFlex 7025 to an outlet box
• Using the 110 Punch down Block
Mounting the ZoneFlex 7025 to an outlet box
1 Prepare the electrical outlet box.
The ZoneFlex 7025 requires a single-gang electrical outlet box mounted in a wall
cavity. The US version requires a box conforming to NEMA-WD6, with a
minimum depth of 1.4 inches. The EU version requires a box conforming to BS
4662, with a minimum depth of 35mm.
• Remove the outlet box cover from the outlet box.
• Run the required cables through the electrical outlet box allowing sufficient
slack for the cables to reach the not yet installed ZoneFlex 7025.
2 Connect the cables
• Connect an Ethernet cable providing PoE power and network connectivity
to the PoE In LAN 5 / Uplink port using either a standard RJ-45 connector
or the 110 punch-down block. Do not connect both. (Refer to “Using the
110 Punch down Block” on page 102 for punch-down block wiring details).
• If required, connect the cable providing support for pass-through devices to
the Pass Through port.
3 Mount the ZoneFlex 7025.
• Align the mounting bracket with the outlet box so that the two screw holes
line up, and pull the Ethernet cable through the center of the mounting
bracket.
