R700 Access Point
The R700 is a high-performance 802.11ac dual band Access Point.
NOTE The R700 requires a minimum of ZoneFlex firmware version 9.8 and later,
SmartCell Gateway (SCG) 2.1 and later, or virtual SmartCell Gateway (vSCG) 2.5
and later to operate.
The R700 features five LEDs on its front panel and buttons and connectors on its
rear panel.
Front Panel
Figure 32 shows the top view of the R700. For a description of each front panel
part, refer to Ta ble 3 9 .
Figure 32. R700 top view
Table 39. R700 front panel elements
LED Description
Power LED • Off: Off.
• Red: Boot up in process.
• Green: On.
