ZoneFlex 7982 Access Point
NOTE The ZoneFlex 7982 requires a minimum of ZoneFlex firmware version 9.4
and later, SmartCell Gateway (SCG) 1.1 and later, or virtual SmartCell Gateway
(vSCG) 2.5 and later to operate.
The ZoneFlex 7982 features five LEDs on its front panel and buttons and connectors
on its rear panel.
Front Panel
Figure 24 shows the top view of the ZoneFlex 7982. For a description of each front
panel part, refer to Ta ble 2 8 .
Figure 24. ZoneFlex 7982 top view
Table 28. ZoneFlex 7982 front panel elements
LED Description
Power LED • Off: Off.
• Red: Boot up in process.
• Green: On.
