Navigating the Web Interface
You manage the Access Point through a Web browser-based interface that you
can access from any networked computer. Tabl e 45 lists the Web interface features
that are identified in Figure 56.
Figure 56. Elements of the ZoneFlex AP Web Interface
Table 45. ZoneFlex AP Web interface elements
Element Description
Menu Under each category (Status, Configuration, etc.) are options that, when clicked,
open the related workspace in the area to the right.
Tabs Contains additional options for the configuration page. For example, the
Configuration > Wireless page includes one tab for common wireless
configuration and eight tabs for each of the available WLANs.
Workspace This large area displays features, options and indicators relevant to your menu
bar choices.
Logout Button Click this button to log out of the AP.
Help Button Click this button to open a help window with information related specifically to
the options currently displayed in the workspace.
Menu
Workspace
Help Button
Tabs
Logout
Button
