Installing the Access Point
Step 1: Preconfigure the Access Point
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 85
• An administrative computer (notebook computer) with an Ethernet port and a
wireless card installed.
• A Web browser such as Google Chrome, Mozilla Firefox 2.0 (or later) or Microsoft
Internet Explorer 6.0 (or later) installed on the administrative computer
• One Cat5e foil screened twisted pair (FTP) solid Ethernet cable
1. Prepare the Administrative Computer
NOTE The following procedure is applicable if the administrative computer is
running Windows XP or Windows 7. If you are using a different operating system,
refer to the documentation that was shipped with your operating system for
information on how to modify the computer’s IP address settings.
1 On your Windows XP or Windows 7 computer, open the Network Connections
(or Network and Dial-up Connections) control panel according to how the Start
menu is set up:
• On Windows XP, click Start > Control Panel > Network Connections.
• On Windows 7, click Start > Control Panel > Network and Internet >
Network and Sharing Center > Change Adapter Settings.
2 When the Network Connections window appears, right-click the icon for Local
Area Connection, and then click Properties.
Make sure that you configure the Local Area Connection properties, not the Wireless
Network Connection properties.
3 When the Local Area Connection Properties dialog box appears, select
Internet Protocol (TCP/IP) (TCP/IPv4 in Windows 7) from the scrolling list, and
then click Properties. The Internet Protocol (TCP/IP) Properties dialog box
appears.
4 Write down all of the currently active network settings. You will need this
information later when you restore your computer to its current network
configuration.
5 Click Use the following IP address, and then configure the IP address settings
with the values listed in Tabl e 4 2. For a sample configuration, refer to Figure 40.
