Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 14
ZoneFlex 7025 Wired/Wireless Wall Switch
NOTE The ZoneFlex 7025 requires a minimum of ZoneFlex firmware version 9.1
and later, SmartCell Gateway (SCG) 1.1 and later, or virtual SmartCell Gateway
(vSCG) 2.5 and later to operate.
The ZoneFlex 7025 is designed for installation in an electrical junction box. This
section identifies the physical features of each ZoneFlex 7025 Wi-Fi Wall Switch
model that is discussed in this guide. Before you begin the installation process,
Ruckus Wireless recommends that you become familiar with these features.
• ZF7025-US
• ZF7025-EU Model
ZF7025-US
This section describes the physical features of the ZF7025-US model, which is
designed to fit in a standard US-style wall electrical outlet box. The outlet box must
conform to NEMA-WD6, with a minimum depth of 1.4 inches.
Front View Features
The front view of ZF7025-US, shown in Figure 1, features a LAN port door which
covers the four Ethernet Ports, a pass through port and a DC in socket on the right
side. Refer to Tab l e 3 for more information.
