Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 63
Table 33. R500 front panel LEDs
LED Description
PWR •Off: Off.
• Red: Boot up in process.
• Green: On.
DIR •Off: The AP is not being managed by ZoneDirector (standalone
mode).
• Green: The AP is being managed by ZoneDirector.
• Slow flashing green (one flash every two seconds): The AP is being
managed by ZoneDirector, but is currently unable to communicate
with ZoneDirector.
• Fast flashing green (two flashes every second): The AP is being
managed by ZoneDirector and is currently receiving configuration
settings (provisioning) or a firmware update.
AIR •Off: The Access Point is operating in standalone mode or operating
as a root AP (RAP) or a non-mesh AP.
• Green: The AP is functioning as a Mesh AP (MAP), and the wireless
signal to its uplink AP is good.
• Fast flashing green (two flashes every second): The AP is
functioning as a Mesh AP (MAP), and the wireless signal to its
uplink AP is fair.
• Slow flashing green (one flash every two seconds): Mesh
networking is enabled, but the AP is still searching for a mesh
uplink.
Note: The mesh (RAP and MAP) functions are available on the
R500 in a future release.
2.4G •Off: The WLAN service is down.
• Green: The WLAN is up and at least one client is associated.
• Amber: The WLAN is up. No clients are associated.
