Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 67
R600 Access Point
The R600 is a high-performance 3x3 802.11ac dual band Access Point.
NOTE The R600 requires a minimum of ZoneFlex firmware version 9.8.1 and later,
SmartCell Gateway (SCG) 2.5.1 and later, or virtual SmartCell Gateway (vSCG) 3.0
and later to operate.
The R600 features five LEDs on its front panel and buttons and connectors on its
rear panel.
Front Panel
Figure 28 shows the top view of the R600. For a description of the front panel LEDs,
refer to Ta ble 3 3.
Figure 30. R600 top view
