ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 71
WARNING! For units using Power over Ethernet (PoE). These products and all
interconnected equipment must be installed indoors within the same building,
including the associated LAN connections, as defined by Environment A of the IEEE
802.3af Standard.
412VDC
Connect the power adapter (12 VDC/1.25A) to this socket. Power
can also be supplied via the 10/100/1000 PoE port.
Table 38. Behavior of Ethernet port LEDs on the R500
LEDs Description
Off Not connected
Amber + Green Connected to 10Mbps device
Amber Connected to 100Mbps device
Green Connected to 1000Mbps device
Table 37. R600 rear panel element descriptions (Continued)
No. Label Description
