Installing the Access Point
ZoneFlex 7025 Physical Installation
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 103
Figure 48. Punch-down block wiring
White/Orange
Orange
White/Green
Blue
White/Blue
Green
White/Brown
Brown
