Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 38
Rear Panel
The rear panel of the ZoneFlex 7351 features one 10/100/1000 PoE Ethernet port,
power socket and reset button. See Tab l e 18 for a description of each rear panel
part.
Table 18. ZoneFlex 7351 rear panel elements
Number Item Name Description
1 10/100/1000+PoE
Port
One RJ-45 port for a 10/100/1000 PoE (Power over
Ethernet, 802.3af) connection.
2 Power Connect the power adapter (12 VDC/1.25A) to this
socket. Power can also be supplied via the 10/100/
1000 PoE port.
3 RST Button Pressing, and then quickly releasing this internal button
reboots the AP. Pressing and holding it for six seconds
resets the AP to factory default settings.
CAUTION! Resetting the AP to factory default
settings erases all previously configured settings.
