Introducing the ZoneFlex Access Point
Getting to Know the Access Point Features
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 49
DIR LED • Off: The Access Point is not being managed by ZoneDirector
(standalone mode).
• Green: The Access Point is being managed by ZoneDirector.
• Slow flashing green (one flash every two seconds): The Access
Point is being managed by ZoneDirector, but is currently
unable to communicate with ZoneDirector.
• Fast flashing green (two flashes every second): The Access
Point is being managed by ZoneDirector and is currently
receiving configuration settings (provisioning) or a firmware
update.
2.4G LED • Off: The WLAN service is down.
• Green: The WLAN service is up and at least one client is
associated with it.
• Flashing green: The WLAN service is up and no clients are
associated.
5G LED
• Off: The WLAN service is down.
• Green: The WLAN service is up and at least one client is
associated.
• Flashing green: The WLAN service is up and no clients are
associated.
AIR LED • Not used at this time.
Cable antenna
connector
• Type N female coaxial cable connector for in-building DAS
wireless systems.
Table 24. ZoneFlex 7441 front panel elements (Continued)
LED Description
