Installing the Access Point
Before You Begin
ZoneFlex Indoor Access Point 9.8.1 User Guide, 800-70601-001 Rev C 79
ZoneFlex 7962 Orientation
The dome-shaped ZoneFlex 7962 AP has a wider horizontal plane coverage area
(when mounted on the ceiling or desktop) compared to other ZoneFlex APs.
Figure 34. Recommended orientation for maximum horizontal plane coverage
Limited
Reach
Excellent
Reach
Excellent
Reach
Good
Reach
