5 18 HS40 Service Manual
5.4.3.1. Specification
Focused RF Data Interface
BW Data Processing
Spectral Doppler Data Processing
Color Doppler Data Processing
Digital Signal Processing (Pre Processing, Post Processing)
CW IQ data Interface (CWD)
Direct Memory Access
3D Probe Motor Driver
Diagnostic Signal Processing
RTC (Real Time Controller)
PCI-express Interface
5.4.3.2. Digital Signal Processing (DSP) Part
The Back End Board’s MID FPGA (KINTEX325T) consists of the Digital Signal Processing Part,
which transforms the Focused RF Data input by the BF Board into Base-Band IQ Data.
The RF Data input goes through the Gain Control, High-Pass Filtering, Quadrature
Demodulation, and Decimation processes and then is sent to the DMA FPGA so that the Base-
Band IQ Data can be transmitted to the PC SW Module.
