Samsung Multifunction MultiXpress X322 Series User Manual

Understanding display messages
365
15. Troubleshooting
12
Network-related messages
Message Meaning Suggested solutions
802.1x authentication
failed. Please Contact the
System Administrator
Fail to authenticate. Check the network
authentication
protocol. If the
problem persists,
contact your network
administrator.
Can not find a wireless
network. Please check the
wireless environment
The machine cannot find
the wireless network.
Check the status of the
wireless router or
access point, including
its configuration and
power connections, as
well as any devices that
may affect wireless
communication. If the
problem persists,
please call for service.
Failed to connect to Wi-Fi
Direct. Turn off your
mobile device and turn it
on
The machine failed to
connect via Wi-Fi Direct.
Turn the Wi-Fi Direct
feature off and then
back on or reboot the
machine or mobile
device. If the problem
persists, please call for
service.
Failed connection to WPS.
Try again or set up other
wireless connection
The machine failed to
connect via WPS.
Check the WPS settings
(see "Using the WPS
menu" on page 59).
MSOK System Failure:
[error number]. Turn off
then on
There is a problem in the
engine system.
Turn the machine off
and back on again. If
the problem persists,
call for service.
Network cable is
disconnected. Check it
The machine is not
connected with a
network cable.
Connect the machine
to the network with a
network cable.
Network Failure:[error
number]. Turn off then
on. Call for service if the
problem persists
There is a problem in the
network system.
Turn the machine off
and back on again. If
the problem persists,
call for service.
Not connected from the
wireless AP. If you do not
reconnect automatically,
check the wireless
settings
The machine failed to
connect to the wireless
AP(access point or
wireless router).
Check the status of the
access point, including
its configuration and
power connections, as
well as any devices that
may affect wireless
communication. If the
problem persists,
please call for service.
This IP address conflicts
with that of other system.
Check it
The network IP address
you have set is being
used by someone else.
Check the IP address
and reset it if necessary.
Message Meaning Suggested solutions
