Sanyo PLC HF10000L Service Manual

-146-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
12 Y Filter Y Input Filter Band 0 - 7 5
13 C Filter C Input Filter Band 0 - 7 5
14 NTSC/PAL Detect
NTSC/PAL Detect Threshold
0 : 64H/1V - PAL Det.strong
1 : 96H/1V
2 : 128H/1V
3 : 160H/1V - PAL Det.weak
*System - Effective only in Auto
0 - 3 1
2001 CXA2239 Option Board *Effective only for Equipped Optional Board
0 OUT 1 GR C/CR/R_OUT1 Output Gain (COMPONENT) 0 - 15 7
0 OUT 1 GG CV/Y/G_OUT1 Output Gain (COMPONENT) 0 - 15 7
0 OUT 1 GB C/CB/B_OUT1 Output Gain (COMPONENT) 0 - 15 7
5000
Dual-SDI Read Register
[Read Only]
*Effective only for Equipped Optional Board
0 VD STD
Specified Monitor Signal
00 : 720p/60
10 : 1080p/60 1080psf/30
11 : 1080p/30
12 : 1080i/50 1080psf/25
13 : 1080p/25
16 : 1080p/24
17 : 1080psf/24
21 : 1035i/60
22 : 480i/60
24 : 575i/50
255 : No SIGNAL
- -
1 Version Version Info. - -
2 Revision Revision Info. - -
9000 HD-Wireless [Read Only] *Effective only for Equipped Optional Board
0 MAC HW Version 0 - 65535 -
1
MAC SW Version
[Device revision Byte1]
0 - 255 -
2
MAC SW Version
[Device revision Byte2]
0 - 255 -
3
MAC SW Version
[Device revision Byte3]
0 - 255 -
4 Destination
DIP SW
0 : Not used, 1 : USA
2 : EU, 3 : Not used
4 : UK, 5~7 : Not used
8 : JPN, 9~15 : Not used
0 - 15

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
