Sanyo PLC HF10000L Service Manual

-196-
KG2-HF10000L00
PACKING MATERIALS
910 285 9073 HANDLE CARTON-ML6A
610 351 2655 CARTON CASE-KG2A
610 337 1658 CUSHION SPACER-KS3A
610 337 1672 CUSHION FNT-KS3A
610 337 1740 CUSHION BACK-KS3A
910 289 7235 REINFORCEMENT A-ML6A
ACCESSORIES
OWNER’S MANUAL
910 319 5347 COLOR MANAGE INST-B-MM7A
610 354 1372 SETUP INST MANUAL-KG2A-A
610 351 5977 CD-ROM,OWNERS MANUAL-KG2A
945 072 1121 CD-ROM (R.C. MANAGER)
REMOTE CONTROL
645 103 7282 ASSY,REMOCON MXCB(SYANAI)
610 352 4450 RC-BATTERY LID-MXCB
! AC CORD
US 945 069 2902 CORD,POWER-3.0MK,US
EU 945 066 7160 CORD,POWER-3.0MK,EU
UK 945 066 7153 CORD,POWER-3.138MK,UK
BRA 645 102 6996 CARD,POWER-2.5MK,BRA
MISCELLANEOUS
FK2B 610 337 0224 ASSY,COVER LNS SMALL-KS3A
FK2A 610 337 0064 ASSY,COVER LNS LARGE-KS3A
W03 610 337 9906 ASSY,COVER LENS W03-KE3A
A-01 610 353 1335 COMPL,MOUNTING LNS 01-IDJJD
910 301 6659 ASSY,SPACER BF-MY8A
910 319 0588 STRAP COMP-MM7A
910 322 4276 COMPL,STPR CLAMP LNS SFT MM7A
945 073 4855 CABLE,INTERFACE VGA
645 093 1642 CABLE,INTERFACE VGA
652 002 9552 CABLE,INTERFACE VGA
MECHANICAL PARTS
CABINET PARTS
C01 610 336 9716 ASSY CABINET FNT RING-KS3A
C02 610 336 9839 ASSY,HANDLE-KS3A
C03 610 335 9939 ASSY HINGE-KS3A
C04 610 335 9755 COMPL,STAND LEG-KS3A
C05 610 343 6265 BUTTON CONTROL-KH5AL
C06 610 351 6080 CABINET FRONT-KG2A
C07 610 351 6073 CABINET FRONT A-KG2A
C08 610 351 6011 CABINET TOP-KG2A
C09 610 351 7322 CAB TOP COVER SERVICE-KG2A
C10 610 353 2738 CABINET BOTTOM-KG2A
C11 610 351 6134 COVER FILTER-KG2A
C12 610 336 9686 COVER PROJ LNS-KE3A
C13 610 336 1727 DEC INLAY LED-KS3A
C14 610 343 6296 DEC INLAY LED AV PNL-KH5AL
C15 610 336 1680 DEC RC SHEET-KS3A
C16 610 351 6219 DEC SHEET AV-KG2A
C17 610 336 8528 NUT SPECIAL-KS3A
C18 610 345 4160 PANEL COMP A-KH5AL
C19 610 350 5510 PANEL AV-KG2A
C20 945 030 7356 BADGE,SANYO*53.5X12L53.5
CHASSIS PARTS
M01 610 335 9830 ASSY,BOX FILTER-KS3A
M02 910 311 5123 ASSY,HOLDER LNS B-MT8A
M02-1 910 303 9870 ASSY,PWB,LENS-BASE NET MT8A
M02-2 910 318 7175 CORD,4P LENS SHIFT
M02-3 945 042 7344 ASSY,MOTOR(ML6A)
M02-4 945 057 3225 SWITCH,SENSOR X
M02-5 945 057 3232 SWITCH,SENSOR Y
M03 610 335 9779 COMPL,MOUNTING SHUTTER-KS3A
M04 610 336 1833 CASE FILTER A-KS3A
M05 610 336 4889 CASE FILTER B-KS3A
M06 610 351 7339 SERVICE COVER DUCT MAIN-KG2A
M07 610 336 2748 COVER LINE FILTER-KS3A
M08 610 334 3549 GEAR MOTOR-KC3A
M09 610 343 6814 HOLDER COVER LNS-KW7A
M10 610 351 5922 HOLDER POWER PFC-KG2A
M11 610 350 7323 HOLDER POWER MAIN-KG2A
M12 610 336 1949 LATCH FILTER-KS3A
M13 610 336 1796 MOUNTING MIR A-KS3A
M14 610 336 1925 MOUNTING GEAR FILTER-KS3A
M15 610 350 9044 SPACER RAIL SLOT-KL8A
M16 610 351 9890 SPACER AC INLET-KG2A
M17 610 346 3353 SPACER MAIN POWER BTM-KE8A
M18 610 351 8220 SPACER SHEET PWB MAIN-KG2A
M19 610 352 9189 SPACER BST BLOW-KG2A
M20 610 338 1305 SPACER CASE FILTER A-KS3A
M21 610 338 1282 SPACER CASE FILTER B-KS3A
M22 610 338 1350 SPACER CASE FILTER C-KS3A
M23 610 337 9760 SHIELD POWER A-KS3A
M24 610 337 9692 SHIELD POWER SHEET-KS3A
M25 610 351 7568 SHIELD AC INLET-KG2A
M26 610 346 1489 OPTICAL BASE BTM-KE8A
M27 610 346 1496 OPTICAL BASE TOP-KE8A
M28 610 350 6609 OPTICAL LMP TOP-KG2A
M29 610 350 6593 OPTICAL LMP BTM-KG2A
M30 610 346 1472 COVER YE LCD-KE8A
M31 610 336 9921 COMP,HOLDER SHAFT FILTER-KC3A
SCREWS
S01 412 076 8000 SPECIAL SCREW V
S02 411 193 4803 SCR BIN 4X30
S03 411 189 8709 SCR BIN 4X10
S04 312 069 6702 SPECIAL SCREW(BLACK)
S05 411 221 9008 SCR BIN+IN TW 3X8
S06 411 192 8703 BOLT HEX-SCT+SW+W 3X6
S07 411 191 2603 BOLT HEX-SCT+SW+W 2.5X8
S08 411 221 0906 SCR OVL 2X4
OPTICAL PARTS
TYPE-L LED PANEL/PRISM ASSY
L01L 610 351 7346 ASSY,PNL/PSM L-KG2A
L01L-R 645 102 7498 LCD(LCX112AAL-7 R)
L01L-G 645 102 7504 LCD(LCX112ABL-8 G)
L01L-B 645 102 7511 LCD(LCX112AAL-6 B)
TYPE-R LED PANEL/PRISM ASSY
L01R 610 351 7353 ASSY,PNL/PSM R-KG2A
L01R-R 645 102 7528 LCD(LCX112ABL-7 R)
L01R-G 645 102 7535 LCD(LCX112AAL-8 G)
L01R-B 645 102 7542 LCD(LCX112ABL-6 B)
Key No. Part No. Description
Key No. Part No. Description
Note: Parts order must contain Chassis No., Part No., and Descriptions.
Mechanical Parts List

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
