Sanyo PLC HF10000L Service Manual

-197-
KG2-HF10000L00
Mechanical Parts List
COMMON
* Key No. L01-R1 to L01-B2 are included in the LCD Panel/Prism Assy.
L01-R1 645 101 6461 PRE-POLARIZED GLASS(OUT)R
L01-R2 645 103 4632 POLARIZED GLASS(OUT/R)
L01-G1 645 104 1609 POLARIZED GLASS(OUT/G)1
L01-G2 645 104 1616 POLARIZED GLASS(OUT/G)2
L01-B1 645 104 1135 POLARIZED GLASS(OUT/B)1
L01-B2 645 103 3734 POLARIZED GLASS(OUT/B)2
L02L-R 645 103 4793 OPTICAL FILTER (ICV)
L02L-G 645 103 4809 OPTICAL FILTER (ICV)
L02L-B 645 103 4793 OPTICAL FILTER (ICV)
L02R-R 645 103 4809 OPTICAL FILTER (ICV)
L02R-G 645 103 4793 OPTICAL FILTER (ICV)
L02R-B 645 103 4809 OPTICAL FILTER (ICV)
L03-R 645 103 4625 POLARIZED GLASS(IN/R)
L03-G 645 103 2447 POLARIZED GLASS(IN/G)2
L03-B 645 103 6711 OPTICAL FILTER(IN/B)2
L04-R 645 092 9984 PREPOLARIZED GLASS(IN/R)
L04-G 645 103 4649 POLARIZED GLASS(IN/G)1
L04-B 645 103 4663 POLARIZED GLASS(IN/B)1
L05 645 103 4724 PRISM(PBS)
L06 645 103 4717 LENS,INTEGRATER(2K)
L07 645 095 0261 LENS,CONDENSER(IN)
L08 645 095 0278 LENS,CONDENSER(OUT)
L09 645 095 0285 LENS,CONDENSER(G)
L10 645 102 4572 LENS,CONDENSER(R)
L11 645 095 0308 LENS,CONDENSER(B)
L12 645 095 0315 LENS,RELAY(IN)
L13 645 097 3499 LENS,RELAY(OUT)
L14 645 095 0339 MIRROR(W-COLD)
L15 645 095 0346 MIRROR(R)
L16 645 095 0353 MIRROR(B)
L17 645 095 0407 MIRROR(HALF)
L18 645 095 0438 OPTICAL FILTER(UV/IR)
L19 645 101 9271 DICHROIC MIRROR (C)
L20 645 095 0421 DICHROIC MIRROR (Y)
L21 645 100 9739 OPTICAL FILTER(LC-CS)
* There are 2 types (Type-L or Type-R) of LCD Panel/Prism Assy. Used type
is indicated on the Prism Assy and Optical unit top. Refer to item “LCD
Panel/Prism Assy Removal” for further information.
SERVICE TOOLS
910 304 8209 ASSY,CG ADJUST LCD-MT8A
610 337 6394 OPTICAL FILTER-S
610 343 5596 PROJECTOR SERVICE CD-ROM V 4.20
Key No. Part No. Description
Key No. Part No. Description

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
