Sanyo PLC HF10000L Service Manual

-156-
Troubleshooting
PFC
MAIN
POWER(AC)
K16E
K47E
K16A
K16C
PFC1
CIRCUIT
PFC2
CIRCUIT
Q1657
Q1608 Q1658
Q1607
RL1601
1
2
RL1651
IC1651
IC1601
K16B
PFC1_SW_PFC2_SW
Lamp-On: H
PF_PFC1/PF_PFC2
Error: L
LAMP2
BALLAST2
CN1C
CN2C
CN3C
LAMP1
BALLAST1
CN1B
CN2B
CN3B
PFC2_SW PFC1_SW
PF_PFC2
PF_PFC1
PFC_SW4
PFC_SW3
PF_PFC4
PF_PFC3
PFC12V2
PFC12V1
7 6 21
7 6 21
PC1651PC1601
Power (PFC)
●Flow chart of projector condition
AC OFF
(with AC power supply and Mains SW : ON)
(90 sec.)
(90 sec.)
(Lamp : OFF)
(Lamp : ON)
(Lamp : OFF)
<ACCIDENT>
(20 sec.)
(15 sec.)
(B)
(A)
(with signal or any button)
(with signal
or any button)
(no signal for 30 sec.)
(no signal for
user setting time)
STAND-BY COOLING
POWER ON POWER OFF WARNING
NORMAL
LAMP TIME
DISPLAY
SERVICE
MODE
SUSPEND
COUNTDOWN
SUSPEND
COOLING
<RECOVER>
<ACCIDENT>
(Lamp error)
SUSPEND
(ON/OFF button
or SERIAL)
(Lamp : ON)
(ON/STAND-BY button)
(ON/OFF button)
(A) : Press and hold MENU and SELECT
buttons on the projector for more
than 3 seconds
(B) : Press and hold POWER ON/STAND-
BY button on the projector or on the
remote control unit for more than 20
seconds.
Check that the lamp drive signals
(PFC1_SW, PFC2_SW) are correct.
Lamp-On: H
If the power failure occurs on the PFC1 or
PCF2 circuit, the detection signal (PF_PFC1,
PF_PFC2) becomes Low.

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
