Sanyo PLC HF10000L Service Manual

-176-
IC Block Diagrams
1
2
3
4
5
6
13
12
11
10
9
8
7
15
16
17
18
19
21
22
23
24
20
14
0
1
2
DISABLE
SELECT
AD8183/AD8185
V CC
V CC
V CC
V CC
V EE
V EE
V CC
V EE
OE
IN0A
IN1A
IN2A
IN2B
IN1B
IN0B
DGND
GND
GND
GND
SEL A/B
OUT0
OUT1
OUT2
DVCC
● AD8183 <RGB-SW & Amp. , IC3071, IC9071>
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
HSCTL
C/HSYNC IN
VIDEO IN
VSEPA
VSYNC IN
CVPOL
CVEXI
CPSEL
GND
POLH
EXIH
POLV
EXIV
VCC
HDRV
CLAMP
VDRV
CPWID
Clamp pulse Gen.
V sync det.
V sync sepa
Sync Sepa.
H Sync det.
Hor. sync
Control
● BA7078AF <Sync Separator, IC5302, IC6301>

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
