Sanyo PLC HF10000L Service Manual

-173-
Control Port Functions
PIN NO. NAME FUNCTION NAME FUNCTION POLARITY I/O
328 D7 POWER_ON_SW Power On O
346 D25 FILTER_COUNT Filter Count I
419 E7 YE_MUTE_SW YE Control O
212 F1 ACCELE_SENS1 Accelerator Sensor 1 I
221 F2 ACCELE_TEMP1 Accelerator Sensor 1 I
322 F3 ACCELE_SENS2 Accelerator Sensor 2 I
415 F4 ACCELE_TEMP2 Accelerator Sensor 2 I
502 F5 R/C_SCX Remote Control (Not used) I
412 G4 PRESS_SENS Pressure Sensor I
499 G5 WINDS_SENS Wind Flow Sensor I
486 Y5 LAMP_ID_SW2 Lamp ID Switch 2 I
563 Y6 FAN_DAC_SCL IIC Bus Clock for Fan Control O
307 AA3 ID_PROG_SW O
400 AA4 ID_PWR_SW O
485 AA5 LAMP_ID_SW1 Lamp ID Switch 1 O
562 AA6 FAN_DAC_SDA IIC Bus Data for Fan Control I/O
205 AB2 LAMP_ID_CLK Lamp ID Clock O
306 AB3 LAMP_ID_BUSY Lamp ID Busy O
399 AB4 LAMP_ID_DATA Lamp ID Data I/O
483 AC5 KEY14 Key Scan Output O
560 AC6 KEY04 Key Scan Input I
94 AD1 KEY13 Key Scan Output O
203 AD2 KEY12 Key Scan Output O
304 AD3 KEY11 Key Scan Output O
559 AD6 KEY03 Key Scan Input I
93 AE1 KEY02 Key Scan Input I
202 AE2 KEY01 Key Scan Input I
303 AE3 BF_POW_SW BP_POW Switch O
397 AE4 GAM1V_ON GAM1V_ON Drive Output O
481 AE5 GAM1.8V_ON GAM1.8V_ON Drive Output O
558 AE6 GAM2.5V_ON GAM2.5V_ON Drive Output O
92 AF1 KEY_POW_ON KEY_POW_ON Drive Output O
302 AF3 GAM3.3V_ON GAM3.3V_ON Drive Output O
480 AF5 ON_25V ON_25V Drive Output O
90 AH1 FOCUS+ Focus Control + O
89 AJ1 FOCUS- Focus Control - O
86 AK3 ZOOM- Zoom Control - O
85 Ak4 ZOOM+ Zoom Control + I / O
● SCALER (IC301, IP00C811)
● I/O Expander (IC4801, M62320FP)
PIN NO. NAME FUNCTION NAME FUNCTION POLARITY I /O
1 SO SO Serial Data Output (not used) O
2 SCL SCL IIC Bus (Clock) I
3 SDA SDA IIC Bus (Data) I/O
4 D0 PF_AV P.Fail Input "L": Abnormality I
5 D1 PF_MOTHER P.Fail Input "L": Abnormality I
6 D2 PF_AD P.Fail Input "L": Abnormality I
7 D3 PF_F_FPGA P.Fail Input "L": Abnormality I
9 D4 PF_TH P.Fail Input "L": Abnormality I
10 D5 PF_PIC P.Fail Input "H": Abnormality I
11 D6 PF_LAN P.Fail Input "H": Abnormality I
12 D7 PF_25V P.Fail Input "H": Abnormality I
● I/O Expander (IC4811, M62320FP)
PIN NO. NAME FUNCTION NAME FUNCTION POLARITY I/O
1 SO SO Serial Data Output (not used) O
2 SCL SCL IIC Bus (Clock) I
3 SDA SDA IIC Bus (Data) I/O
4 D0 PF_I/O P.Fail Input "L": Abnormality I
5 D1 PF_S16V P.Fail Input "L": Abnormality I
6 D2 PF_S3.3V P.Fail Input "L": Abnormality I
7 D3 PF_F_MOTOR P.Fail Input "L": Abnormality I
9 D4 PF_KEY P.Fail Input "L": Abnormality I
10 D5
11 D6 PF_GAM P.Fail Input "H": Abnormality I
12 D7 PF_S-5V P.Fail Input "H": Abnormality I

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
