Sanyo PLC HF10000L Service Manual

-72-
Electrical Adjustment
Service Adjustment Data Table
These initial values are the reference data written from the
CPU ROM to memory IC when replaced new memory IC. The
adjustment items indicated with “✻” are required to readjust fol-
lowing to the “Electrical adjustments”. Other items should be
used with the initial data value.
Grp / No. Item Function Range Initial Note
0 AD Converter A (ADV7842)
3 ADC G-GAIN
PC - On Board / Slot
Component - On board / Slot
Composite - Slot
Scart - Slot
0 - 1023
950 / 950
900 / 900
850
950
4 ADC R-GAIN
PC - On Board / Slot
Component - On board / Slot
Composite - Slot
Scart - Slot
0 - 1023
950 / 950
900 / 900
850
950
5 ADC B-GAIN
PC - On Board / Slot
Component - On board / Slot
Composite - Slot
Scart - Slot
0 - 1023
950 / 950
900 / 900
850
950
6 Auto Coast Analog PC 0 - 1 1
7 Pre Coast Analog PC 0 - 15 4
8 Post Coarst Analog PC 0 - 15 4
1 AD Converter B (ADV7842)
3 ADC G-GAIN
PC - On Board / Slot
Component - On board / Slot
Composite - Slot
Scart - Slot
0 - 1023
950 / 950
900 / 900
850
950
4 ADC R-GAIN
PC - On Board / Slot
Component - On board / Slot
Composite - Slot
Scart - Slot
0 - 1023
950 / 950
900 / 900
850
950
5 ADC B-GAIN
PC - On Board / Slot
Component - On board / Slot
Composite - Slot
Scart - Slot
0 - 1023
950 / 950
900 / 900
850
950
6 Auto Coast Analog PC 0 - 1 1
7 Pre Coast Analog PC 0 - 15 4
8 Post Coarst Analog PC 0 - 15 4
20 AD Converter A (ADV7842 Video)
0 Y Level
Composite - On Board
Scart - On Board
0 - 1023
850
700
1 C Level
Composite - On Board
Scart - On Board
0 - 1023
659
700
2 Analog Clamp Speed Composite - Video 0 - 31 4
21 AD Converter B (ADV7842 Video)
0 Y Level
Composite - On Board
Scart - On Board
0 - 1023
850
700
1 C Level
Composite - On Board
Scart - On Board
0 - 1023
659
700
2 Analog Clamp Speed Composite - Video 0 - 31 4
40 General
0 IP Mode Set at IP OFF 0: Not used IP Block 1: Used IP Block and IP OFF 0 - 1 1
2 Detect Film Mode Enable 0: 2:3pull down & 2:2pull down 1: 2:3pull down 2: 2:2pull down 0 - 2 0
41 Deinterlacer setting Progressive Mode1, Film Parameter
0 Motion Adaptive Weight Value <KDEINT> 0 - 4 2 / 2 / 2
1 Angle Interpolation Level 0 : Conservative <== ==> 4 : Aggressive 0 - 5 3 / 3 / 3
47 Noise Reduction (time) NR L1 Parameter
1 HVNR <NSREGIONY0> / <NSREGIONUV0> 0 - 3 3
2 COBM <NSREGIONY1> / <NSREGIONUV1> 0 - 3 3
4 TBR <NSFILTERY**> / <NSFILTERUV**> 0 - 3 2
50 2:2 pull down setting
0 22 Film Mode Sensitivity Film Detection Sensitivity <FILMSTVT22> 0 - 15 2
51 2:3 pull down setting
0 Global Motion Sensitivity Film Detection Sensitivity <FILMSTVT23> 0 - 15 1
60 Sub Image

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
