Sanyo PLC HF10000L Service Manual

-166-
Troubleshooting
Error
Error
Code
Error Infomation
(See Powe Failure Detection Tree)
Error
Code
Error Infomation
(See Powe Failure Detection Tree)
Normal 0 -
Power Failure
1000 AV, AV 1023 NET, FANDC E
1001 MOTHR, MOTHER 1024 FAN, FAN D1
1002 MAIN, AD 1025 FAN, FAN D2
1003 MAIN, F FPGA 1026 FAN, FAN E
1004 MAIN, TH 1027 MAIN. S5V
1005 MAIN, PIC 1028 MAIN. PFC3
1006 RS232C, LAN 1029 MAIN. PFC4
1007 MAIN, 25V 1030 ERR, PRESSURE
1008 MAIN, I/O 1031 ERR, FIL_DET
1009 MAIN, S16V 1032 ERR, FIL_MTR
1010 MAIN, S3.3V 1033 ERR, SHUT_MTR
1011 MAIN, S12V 1034 ERR, IIC_DATA
1012 MAIN, KEYSTONE 1035 SLOT3,
1013 MAIN, GAMMA 1036 SLOT4,
1014 MAIN, S-5V
1015 SUBPOW, 12VF1
1016 FAN, FAN A
1017 SUBPOW, 12VF2
1018 FAN, FAN B
1019 SUBPOW, 12VF3
1020 FAN, FAN C
1021 NET, FANDC D1
1022 NET, FANDC D2
Temperature Error
2000 Temperature Error detected on the Sensor (IC8811) (Arround the Intake Duct)
2001 Error of the detection (IC8811 communication error)
2100 Temperature Error detected on the Sensor (IC8856) (Arround the B-Panel)
2200 Error of the detection (IC8856 communication error)
Lamp Error
3000 Lamp1 fails on
3001 Lamp1 goes out
3002 Communication Error on Lamp1
3100 Lamp2 fails on
3101 Lamp2 goes out
3102 Communication Error on Lamp2
System Error
4000 Config Error (FPGA, AV, Mother, Ye)
4001 Config Error (FPGA SW, LVDS)
Filter Error 6000 Clogged filter
4003 PW DPORT OUT Error
Error History Log
This projector provides the error history log function. To
check the logs, you need to enter the service mode and
select Group No. "220" and Item No. "0" to "49". The error
code is displayed on the Data column. The description of
the error code is listed on the table below.
* How to enter the service mode and select the group, item
and data value, see "Service Adjustment Menu Opera-
tion".
Group
No.
Item
No.
Data
(Error Code)
91 0
1
2
3
:
:
49
✻
<- Latest Error
✻
✻
✻
:
:
✻
How to reset the Error History Log
1. Enter the Service Mode, and select Group No. "220" and Item No. "50".
2 The history log will be reset when the Data Value is set to "10". The value automatically returns to "0".
* How to enter the service mode and select the group, item and data value, see "Service Adjustment Menu Operation".

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
