Sanyo PLC HF10000L Service Manual

-73-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
0 Center Contrast
Group
Composite / S-Video / Component / Digital /D-RGB-Video
/AnalogRGB / RGB-Video / HDCP-PC /HDCP-AV /SCART/ PJ-
Net
Value = (Menu Value - Menu Center) x Alpha / 10 + Center
(Effective Range)
Contrast [Max] 1023 [Min] 0
Brightness [Max] 1023 [Min] 0
Color [Max] 1023 [Min] 0
Tint [Max] 180 [Min] 0
Sharpness [Max] 57 [Min] 0 (Dummy)
WB R/G/B [Max] 1023 [Min] 0
BB R/G/B [Max] 1023 [Min] 0
Fixed Sharpness Up/Down [Max] 37 [Min] 0
0 - 1023
673/373/577/492/492/533/533/492/
492/533/492
1 Center Brightness 0 - 1023
512/512/512/512/512/512/
512/512/512/495/512
2 Center Color 0 - 1023
512/512/512/512/512/512/
512/512/512/495/512
3 Center Tint 0 - 180 90/90/90/90/90/90/90/90 /90/90/90
4 Fixed Sharpness(Up Scaling) 0 - 21 10/10/10/10/10/10/10/10/10/10/10
5 Fixed Sharpness(Down Scaling) 0 - 21 10/10/10/10/10/10/10/10/10/10/10
6 Center Sharpness(No FPGA) 0-37
7 Center WB Red 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
8 Center WB Green 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
9 Center WB Blue 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
10 Center BB Red 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
11 Center BB Green 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
12 Center BB Blue 0 - 1023
512/512/512/512/512/512
/512/512/512/512/512
13 Alpha Contrast 0 - 1000 60/60/60/60/60/60/60/60/60/60/60
14 Alpha Brightness 0 - 1000 90/90/90/90/90 /90/90/90/90/90/90
15 Alpha Color 0 - 1000
140/140/140/140/140/140
/140/140/140/140/140
16 Alpha Tint 0 - 1000 10/10/10/10/10/10/10/10/10/10/10
17 Alpha Sharpness 0 - 1000 10/10/10/10/10/10/10/10/10/10/10
18 Alpha WB Red 0 - 1000 40/40 /40/40/40/40/40/40/40/40/40
19 Alpha WB Green 0 - 1000 40/40 /40/40/40/40/40/40/40/40/40
20 Alpha WB Blue 0 - 1000 40/40 /40/40/40/40/40/40/40/40/40
21 Alpha BB Red 0 - 1000 20/20/20/20/20/20/20/20/20/20/20
22 Alpha BB Green 0 - 1000 20/20/20/20/20/20/20/20/20/20/20
23 Alpha BB Blue 0 - 1000 20/20/20/20/20/20/20/20/20/20/20
80 FINE FPGA - Setting
0 UV_DLT 0 - 31 3
1 UV_GAIN 0 - 2047 1030
2 UV_SFT 0 - 32767 6180
3 Demo On/Off Demo Mode On/Off (1:ON,0:Off) 0 - 1 0
4 Demo Mode Demo Mode Swith (0:Demo0,1:Demo1...) 0 - 7 0
5 Area Big Chg 0 - 4095 67
6 Area Small Chg 0 - 4095 67
7 Area Chg Sens 0 - 4095 150
8 Show Mode o: Normal, 1: Show1, 2:Show2 0 - 3 0
9 PW Mute PW Mute Signal Switch 0: Off, 1: On 0 - 1 0
81 FINE FPGA - Color Management
0 Y Range 0 - 32 8
1 Hue Range 0 - 20 10
2 Gain Range 0 - 50 30
3 GM Min Slope Gamma Correction Mini Slope 0 - 10 3
4 GM Max Slope Gamma Correction Max Slope 10 - 30 18
5 GM Converse Gamma Correction Converse Points 1 - 5 3
6 Not used
7 Not used
8 COLM_GET_LIND_Y_ud No. Points 1 - 9 9
9 Not used
10 Not used
11 Same Hue 1 - 10 3
12 Cut UV Norm 0 - 64 5
13 Cur MinY 0 - 127 0
14 Cur MaxY 125 - 255 255
15 Conv Y 0 - 63 24
16 Same Y 0 - 127 64
17 WB Limit 0 0 - 255 4
18 WB Limit 1 0 - 255 40
19 WB Limit 2 0 - 255 41
20 WB Limit 3 0 - 255 41
21 WB Limit 4 0 - 255 41
22 WB Limit 8 0 - 255 41
23 WB Limit In 0 - 255 14

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
