Sanyo PLC HF10000L Service Manual

-74-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
24
WB Linit Out
0 - 255 20
25 WB Limit PtFlg 0 - 1 1
82 FPGA - Ye Overlay TYPE-L TYPE-R * Panel Type
0 DEC_R R Subtraction 0 - 255 170 150
1 DEC_G G Subtraction 0 - 255 10 30
2 B_RATIO B Addition 0 - 255 15 15
3 SAT_SLOPE Saturation Overlay 0 - 255 71 71
4 R_SLOPE R Hue Overlay 0 - 255 70 70
5 G_SLOPE G Hue Overlay 0 - 255 77 77
6 LUM_MAX PC-Standard 0 - 255 255 255
7 LUM_MAX PC-Rear 0 - 255 160 160
8 LUM_MAX PC-Dynamic 0 - 255 255 255
9 LUM_MAX AV-Standard 0 - 255 160 160
10 LUM_MAX AV-Cinema 0 - 255 160 160
11 LUM_MAX AV-Dynamic 0 - 255 255 255
12 LU_MIN PC-Standard 0 - 255 0 0
13 LU_MIN PC-Rear 0 - 255 0 0
14 LU_MIN PC-Dynamic 0 - 255 0 0
15 LU_MIN AV-Standard 0 - 255 0 0
16 LU_MIN AV-Cinema 0 - 255 0 0
17 LU_MIN AV-Dynamic 0 - 255 0 0
18 YE_SENS 0 - 255 4
19 YE_TESTFLG 0 - 255 3
20 DAC_MAX Not used 0 - 255 255
21 DAC_MIN Not used 0 - 255 0
22 DAC_UseMin DAC Level at Power Off 0 - 255 0
23 YE_FX_VAL PC-Standard 0 - 255 60
24 YE_FX_VAL PC-Rear 0 - 255 60
25 YE_FX_VAL PC-Dynamic 0 - 255 60
26 YE_FX_VAL AV-Standard 0 - 255 60
27 YE_FX_VAL AV-Cinema 0 - 255 60
28 YE_FX_VAL AV-Dynamic 0 - 255 60
29 DAC_Range Max 0 - 255 255
30 DAC_Range Min 0 - 255 32
31 P_PWM_WIDTH 0 - 16383 600
32 DAC_LEVEL For Ye Auto 0 - 255 255
33 YE_APLUsed APL usage 0 - 255 20
34 YE_APLOff 0 - 255 0
35 YE_FIX_VAL_SW PC-Standard 0 - 1 1
36 YE_FIX_VAL_SW PC-Rear 0 - 1 1
37 YE_FIX_VAL_SW PC-Dynamic 0 - 1 1
38 YE_FIX_VAL_SW AV-Standard 0 - 1 1
39 YE_FIX_VAL_SW AV-Cinema 0 - 1 1
40 YE_FIX_VAL_SW AV-Dynamic 0 - 1 1
41 YE_APL_A0 0 - 127 30
42 YE_APL_A1 0 - 127 62
43 YE_APL_A2 0 - 127 75
44 YE_APL_A3 0 - 127 90
45 YE_APL_A4 0 - 127 100
46 YE_GAIN_A0 - 256 - 256 -20
47 YE_GAIN_A1 - 256 - 256 -12
48 YE_GAIN_A2 - 256 - 256 -4
49 YE_GAIN_A3 - 256 - 256 13
50 YE_GAIN_A4 - 256 - 256 30
51 YE_APL_B0 0 - 127 8
52 YE_APL_B1 0 - 127 19
53 YE_APL_B2 0 - 127 30
54 YE_APL_B3 0 - 127 38
55 YE_APL_B4 0 - 127 45
56 YE_GAIN_B0 - 256 - 256 20
57 YE_GAIN_B1 - 256 - 256 26
58 YE_GAIN_B2 - 256 - 256 43
59 YE_GAIN_B3 - 256 - 256 70
60 YE_GAIN_B4 - 256 - 256 100
61 YE_APL_C0 0 - 127 7
62 YE_APL_C1 0 - 127 25
63 YE_APL_C2 0 - 127 40
64 YE_APL_C3 0 - 127 50
65 YE_APL_C4 0 - 127 60

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
