Sanyo PLC HF10000L Service Manual

-75-
Electrical Adjustment
Grp / No. Item Function Range Initial Note
66 YE_GAIN_C0 0 - 511 300
67 YE_GAIN_C1 0 - 511 278
68 YE_GAIN_C2 0 - 511 207
69 YE_GAIN_C3 0 - 511 120
70 YE_GAIN_C4 0 - 511 100
71 YEOFF_YE_SW 0 - 1 1
72 YEOFF_YE_LVL 0 - 255 255
73 COLOR_AJY 0 - 16383 128
83 FINE FPGA Sharpnes
0 Sharpness MIN [PC-SD] 0 - 127 0
1 Sharpness MIN [PC-HD] 0 - 127 0
2 Sharpness MIN [AV-SD] 0 - 127 0
3 Sharpness MIN [AV-HD] 0 - 127 0
4 Sharpness CENTER [PC-SD] 0 - 127 35
5 Sharpness CENTER [PC-HD] 0 - 127 30
6 Sharpness CENTER [AV-SD] 0 - 127 46
7 Sharpness CENTER [AV-HD] 0 - 127 35
8 Sharpness MAX [PC-SD] 0 - 127 100
9 Sharpness MAX [PC-HD] 0 - 127 100
10 Sharpness MAX [AV-SD] 0 - 127 77
11 Sharpness MAX [AV-HD] 0 - 127 70
84 FINE FPGA - Blending
0 BKMOD
0: Blending Mode (NORMAL) Layered Disable
1: Blending Mode (BLANKINK)Layered Disable
2: Blending Mode (NORMAL)Layered Enable
3: Blending Mode (BLANKING)Layered Enable
0 - 3 3
1 BLD_I_SIZE_H Inner Frame Width H 0 - 255 0
2 BLD_I_SIZE_V Inner Frame Width V 0 - 255 0
3 BLD_CURVE Curve 0 - 255 0
4 RGB_GAIN PC-Standard 0 - 511 256
5 RGB_GAIN PC-Real 0 - 511 256
6 RGB_GAIN PC-Dynamic 0 - 511 256
7 RGB_GAIN AV-Standard 0 - 511 256
8 RGB_GAIN AV-Cinema 0 - 511 256
9 RGB_GAIN AV-Dynamic 0 - 511 256
10 Bld_Exp_Int PC-Standard 0 -255 125
11 Bld_Exp_Int PC-Real 0 -255 125
12 Bld_Exp_Int PC-Dynamic 0 -255 125
13 Bld_Exp_Int AV-Standard 0 -255 125
14 Bld_Exp_Int AV-Cinema 0 -255 125
15 Bld_Exp_Int AV-Dynamic 0 -255 125
16 Bld_off_mult PC-Standard 0 -255 64
17 Bld_off_mult PC-Real 0 -255 64
18 Bld_off_mult PC-Dynamic 0 -255 64
19 Bld_off_mult AV-Standard 0 -255 64
20 Bld_off_mult AV-Cinema 0 -255 64
21 Bld_off_mult AV-Dynamic 0 -255 64
85 AV FPGA Dot Clock Rate
1 PC-Dot Clock Rate Slot-DIgtal 1002
2 AV-Dot Clock Rate Slot-DIgital 1002
86 MOTHER FPGA DLYCNT
0 DLYCNT (SLOT1) SLOT1 Clock Phase [DVI-Dsub] 0 - 255 7
1 DLYCNT (SLOT1) SLOT1 Clock Phase [HDCP-DVI] 0 - 255 7
2 DLYCNT (SLOT1) SLOT1 Clock Phase [Dual Fanc-SDI] 0 - 255 3
3 DLYCNT (SLOT1) SLOT1 Clock Phase [Dual Link-SDI] 0 - 255 3
4 DLYCNT (SLOT1) SLOT1 Clock Phase [AMIMON] 0 - 255 3
5 DLYCNT (SLOT1) SLOT1 Clock Phase [Reserved] 0 - 255 1
6 DLYCNT (SLOT1) SLOT1 Clock Phase [Reserved] 0 - 255 1
7 DLYCNT (SLOT1) SLOT1 Clock Phase [Reserved] 0 - 255 1
8 DLYCNT (SLOT1) SLOT1 Clock Phase [Reserved] 0 - 255 1
9 DLYCNT (SLOT1) SLOT1 Clock Phase [Reserved] 0 - 255 1
10 DLYCNT (SLOT2) SLOT2 Clock Phase [DVI-Dsub] 0 - 255 7
11 DLYCNT (SLOT2) SLOT2 Clock Phase [HDCP-DVI] 0 - 255 7
12 DLYCNT (SLOT2) SLOT2 Clock Phase [Dual Fanc-SDI] 0 - 255 3
13 DLYCNT (SLOT2) SLOT2 Clock Phase [Dual Link-SDI] 0 - 255 3
14 DLYCNT (SLOT2) SLOT2 Clock Phase [AMIMON] 0 - 255 3
15 DLYCNT (SLOT2) SLOT2 Clock Phase [Reserved] 0 - 255 1

Sanyo PLC HF10000L Specifications

General

Matrix size	1.65 \
Matrix type	3-panel (p-Si TFT active)
Projection distance	- m
Vertical scan range	48 - 100 Hz
Horizontal scan range	15 - 120 kHz
Projection technology	LCD
Contrast ratio (typical)	3000:1
Screen size compatibility	- \
Projector native resolution	-
Keystone correction, horizontal	30 °
Interface	USB
Power LED	Yes
RS-232 ports	2
Dimensions (WxDxH)	530 x 757 x 268 mm
Focus	Auto
Focal length range	- mm
Noise level	43 dB
Noise level (economic mode)	39 dB
Dot clock scanning frequency	230 MHz
Lamp power	380 W
Lamps quantity	2 lamp(s)
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Composite video in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	1
Wi-Fi	No
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1200 (WUXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
Product color	Gray
Power consumption (standby)	18 W
Power consumption (typical)	955 W
Cables included	AC, RS-232

Weight and Dimensions

Weight	27600 g
