Key No. Part No. Description Key No. Part No. Description

KG2-HF10000L00

-199-

Electrical Parts List

ASSEMBLED BOARDS

! AA9000 610 349 9017 ASSY,PWB,MOTHER.KL8A

! AA1200 610 349 9024 ASSY,PWB,AV.KL8A

! AA3800 610 349 9031 ASSY,PWB,RS232C.KL8A

! AA3850 610 350 3479 ASSY,PWB,ILLUMI SENSOR. KL8A

! AA680 610 353 8396 ASSY,PWB,PFC KG2A

! A6501 610 351 0217 ASSY,PWB,MOTOR KG2A

! A6590 610 351 0231 ASSY,PWB,LENS NET KG2A

! A2680 610 351 0248 ASSY,PWB,LINE FILTER KG2A

! A2821 610 351 0279 ASSY,PWB,RC FRONT KG2A

! A2801 610 351 0286 ASSY,PWB,RC REAR KG2A

! A2851 610 351 0255 ASSY,PWB,LED KG2A

! AA6594 610 351 0262 ASSY,PWB,LIGHT KG2A

! A6581 610 351 0293 ASSY,PWB,FILTER SW KG2A

! A2691 610 351 0309 ASSY,PWB,FG NET KG2A

! A7761 610 351 0323 ASSY,PWB,RGB FANNET KG2A

! A7701 610 351 0347 ASSY,PWB,LAMP FANNET KG2A

! AA5501 610 351 0330 ASSY,PWB,AMF DRIVER KG2A

! A8811 610 351 0378 ASSY,PWB,EX TEMP. KG2A

! A8740 610 351 0408 ASSY,PWB,LAMP ID1 IF KG2A

! A8750 610 351 0385 ASSY,PWB,LAMP ID2 IF KG2A

! A6591 610 351 0392 ASSY,PWB,HALL SENSOR KG2A

! AA200 610 351 7254 ASSY,PWB,MAIN.KG2A

! AA6800 610 351 7261 ASSY,PWB,MAIN CONTROL.KG2A

OUT OF CIRCUIT BOARD

! LP903 610 351 5939 COMPL,OPT LMP-KG2A

! LP904 610 351 5939 COMPL,OPT LMP-KG2A

L901 945 044 3818 CORE,CLAMP

945 050 8418 CORE,CLAMP

L902 945 044 3818 CORE,CLAMP

945 050 8418 CORE,CLAMP

L906 945 020 3641 CORE,FERRITE

! A601 645 103 2379 UNIT,POWER(AC)

! A901 645 103 2386 UNIT,POWER(DC)

! BALAST1 645 103 2416 UNIT,BALLAST

! BALAST2 645 103 2416 UNIT,BALLAST

! F901 323 028 4202 FUSE 300V 15A

! F901A 645 089 9355 HOLDER,FUSE

! FN901 645 095 0698 MOTOR,BLW DC 9.24W

! FN902 645 095 0698 MOTOR,BLW DC 9.24W

! FN903 645 095 0704 MOTOR,BLW DC 9.24W

! FN904 645 095 0698 MOTOR,BLW DC 9.24W

! FN905 645 101 1770 MOTOR,FAN DC 2.28W

! FN906 645 101 1770 MOTOR,FAN DC 2.28W

! FN907 645 095 0704 MOTOR,BLW DC 9.24W

! FN908 945 078 8780 MOTOR,BLW DC 7.08W

! FN909 945 078 8780 MOTOR,BLW DC 7.08W

! FN910 645 103 6599 MOTOR,BLW DC 3.6W

! FN911 645 103 6599 MOTOR,BLW DC 3.6W

! FN912 645 095 0742 MOTOR,BLW DC 2.76W

! K901 945 040 7599 SOCKET,INLET AC 3P

K901D 610 351 3379 HOLDER AC INLET US-KG2A

K901E 610 336 1703 HOLDER INLET 15A BASE-KS3A

K901F 610 353 3360 HOLDER AC INLET COVER-KG2A

M901 645 093 2571 MOTOR,DC 12V

S901 645 093 2533 UNIT,WIND VELOCITY SENSOR

645 103 4106 UNIT,WIND VELOCITY SENSOR

! SW901 645 102 6781 SWITCH,POWER 4P-2TX2

SW902 945 076 8164 SWITCH,PUSH 1P-2TX1

! SW903 645 102 4527 SWITCH,REED

! SW904 645 102 4527 SWITCH,REED

! W7C3 610 339 2141 CABLE,BALLAST SERVICE KS3A

! W7C4 610 339 2141 CABLE,BALLAST SERVICE KS3A

ZA1200A 312 067 3604 SPECIAL SCREW

ZA1200B 312 067 3604 SPECIAL SCREW

ZA1200C 312 067 3604 SPECIAL SCREW

ZA1200D 312 067 3604 SPECIAL SCREW

AA9000 610 349 9017 ASSY,PWB,MOTHER.KL8A

TRANSISTOR

Q9501 305 217 4913 TR RN1111 TE85L

Q9502 305 217 4913 TR RN1111 TE85L

Q9511 305 217 4913 TR RN1111 TE85L

Q9512 305 217 4913 TR RN1111 TE85L

Q9521 305 217 4913 TR RN1111 TE85L

Q9522 305 217 4913 TR RN1111 TE85L

Q9531 305 217 4913 TR RN1111 TE85L

Q9532 305 217 4913 TR RN1111 TE85L

Q9541 305 217 4913 TR RN1111 TE85L

Q9542 305 217 4913 TR RN1111 TE85L

INTEGRATED CIRCUIT

IC9071 309 470 2617 IC AD8183ARUZ-REEL7

IC9091 310 456 7905 IC TC74VHC244FT

IC9131 310 386 1905 IC TC74VCX125FT

IC9171 310 362 6504 IC TC74LCX541FT

IC9501 409 699 6516 IC TA48S00AF

IC9511 409 699 6516 IC TA48S00AF

IC9521 409 699 6615 IC BD7820FP

IC9531 409 699 6615 IC BD7820FP

IC9541 309 553 4712 IC PQ070XZ02ZP

IC9551 309 461 7822 IC PQ20WZ11

IC9561 309 553 4712 IC PQ070XZ02ZP

IC9571 309 461 7822 IC PQ20WZ11

CAPACITOR

C9001 303 438 0219 CERAMIC 0.1U K 16V
